MIYANO BNA-42MSY - Tweedehands machine
Verkocht
| Jaar | 2012 |
| Asnummer | 8 |
| Aantal spindels | 2 |
| Spindelslag | 100 mm |
| Rotatiesnelheid van de as | 6000 Tr/min |
| Carriage stroke | 5000 mm |
| Vermogen op hoofdspil | 5.5/3.7 KW |
| Max. diameter | 34 mm |
| Number of fixed stations on turret | 8 |
| Aantal roterende gereedschappen | 8 |
| Formaten | 2388x1450x1620 mm |
| Gewicht | 3000 Kg |
– Main and counter spindle with Y and C axis
– Operating time of the spindle 10’362 hours
Equipment
– Bar feeder LNS 542
– Chip conveyor LNS
– Workpiece conveyor
– Kraft & Bauer fire extinguishing system
– HD New England System
– ELBARON electrostatic air cleaner
– 2 x collet chucks
– Various collets
– Various tool holders
– Various LNS guide channels
