MIYANO BNA-42MSY - Used machine
SOLD
| Year | 2012 |
| Axis number | 8 |
| Number of spindles | 2 |
| Spindle stroke | 100 mm |
| Spindle speed | 6000 RPM |
| Carriage stroke | 5000 mm |
| Spindle power | 5.5/3.7 KW |
| Max. diameter | 34 mm |
| Turret | 8 |
| Number of rotary tools | 8 |
| Dimensions | 2388x1450x1620 mm |
| Weight | 3000 Kg |
– Main and counter spindle with Y and C axis
– Operating time of the spindle 10’362 hours
Equipment
– Bar feeder LNS 542
– Chip conveyor LNS
– Workpiece conveyor
– Kraft & Bauer fire extinguishing system
– HD New England System
– ELBARON electrostatic air cleaner
– 2 x collet chucks
– Various collets
– Various tool holders
– Various LNS guide channels
